Meshless melt laser filter

Heiko company uses a new concept to design and manufacture high-performance automatic cleaning melt filter products...
 In-line filtration, no need to change the screen
 High production capacity, fully automatic slag discharge
 Smooth melt pressure
 Tight sealing structure type

automatic Screen-Changer

ONLINE CHAT

DETAILS
CONFIGURATION
RELATED
FAQS
LEAVE MESSAGE

DETAILS

◆ Heiko company uses a new concept to design and manufacture high-performance automatic clean melt filter products, using advanced laser process processing technology, to achieve filtration of pollutants without the use of filter screens, and then assist in the use of special special scrapers to fully scrape the material, clean and thorough scraping of impurities and pollutants, to achieve automatic slag discharge, efficient filtration and removal of pollutants, widely used in all kinds of waste and post-consumer recycled plastics large-output coarse filtration process.

Performance characteristics:

◆ On-line filtration, no need to change the screen

◆ High production capacity, automatic slag discharge

◆ Large filtration area, efficient filtration of pollutants

◆ Smooth melt pressure

◆ Tight sealing structure type

◆ Very low material loss

◆ Long-lasting stable performance

Scope of application

◆ It is widely used in the large-output coarse filtration process of various post-consumer recycled plastics.

◆ Widely used in XPS extruded plastic board, granulation, sheet plate, pipe, etc.

CONFIGURATION

Product model	yield (Kg/h)	Filter diameter (mm)	Filtration accuracy (meshes)	Pressure-resistant (MPa)	Drive power (KW)	Discharge Power (KW)	Heating power (KW)
HK-DR-2N-300	300—500	300×2	10—100	≤35	3	1.1	18
HK-DR-2N-350	400—1000	350×2	10—100	≤35	4	1.1	21
HK-DR-2N-400	500—1200	400×2	10—100	≤30	4	1.1	25
HK-DR-2N-500	1000—2000	500×2	10—100	≤30	5.5	2.2	30
HK-DR-2N-700	2000—3500	700×2	10—100	≤30	7.5	2.2	42
